Flutter开发-启动页

https://flutter.cn/docs/development/ui/advanced/splash-screen

安卓启动页

在android\app\src\main\res\drawable-v21\launch_background.xml

1
2
3
4
5
6
7
8
9
10
11
12
13
<?xml version="1.0″ encoding="utf-8″?>
<!– Modify this file to customize your launch splash screen –>
<layer-list xmlns:android="http://schemas.android.com/apk/res/android">
    <item android:drawable="@android:color/white" />
    <!– You can insert your own image assets here –>
     <!-- <item>
        <bitmap
            android:gravity="center"
            android:src="@mipmap/aeologic_logo" />
    </item> -->
    //这样写可以通过图片铺满整个屏幕，不同屏幕可能会有拉伸
    <item android:drawable="@mipmap/splash_bg">
</layer-list>

将里面的内容反注释，图片分辨率1080 x 1920放入android\app\src\main\res\mipmap-xxhdpi。

背景颜色，因为Android自带的颜色只有white和black。

想自定义颜色，需要把原来的 @android:color/white”中的android:去掉即可。

去掉以后为

1
<item android:drawable="@color/other" />

其中other是自定义的颜色。

首先需要在android\app\src\main\res\values下新建一个colors.xml文件，

内容为

1
2
3
4
5
<?xml version="1.0″ encoding="utf-8″?>
<resources>
<color name="other">#0397ff</color>
<color name="transparent">#00000000</color>
</resources>

IOS启动页

Flutter启动页

配置图片视频资源

1
2
3
4
5
6
7
8
9
10
flutter:
  uses-material-design: true
  assets:
    - assets/videos/aeologic_logo.mp4
    - assets/images/aeologic_logo.png
    - assets/images/animation.png
    - assets/images/image.png
    - assets/images/video.png
    - assets/images/logo.png
    - assets/images/powered_by.png

静态

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
import 'package:flutter/material.dart';
import 'package:test2/splash/ImageSplashScreen.dart';

void main() {
  runApp(MyApp());
}

class MyApp extends StatelessWidget {
  @override
  Widget build(BuildContext context) {
    return MaterialApp(
      title: 'Flutter Splash Demo',
      theme: ThemeData(
        primarySwatch: Colors.blue,
      ),
      home: ImageSplashScreen(),
      routes: <String, WidgetBuilder>{
        "/home": (BuildContext context) =>
            MyHomePage(title: 'Flutter Demo Home Page'),
      },
    );
  }
}

class MyHomePage extends StatefulWidget {
  MyHomePage({Key? key, required this.title}) : super(key: key);
  final String title;
  @override
  _MyHomePageState createState() => _MyHomePageState();
}

class _MyHomePageState extends State<MyHomePage> {
  int _counter = 0;

  void _incrementCounter() {
    setState(() {
      _counter++;
    });
  }

  @override
  Widget build(BuildContext context) {
    return Scaffold(
      appBar: AppBar(
        title: Text(widget.title),
      ),
      body: Center(
        child: Column(
          mainAxisAlignment: MainAxisAlignment.center,
          children: <Widget>[
            Text(
              'You have pushed the button this many times:',
            ),
            Text(
              '$_counter',
              style: Theme.of(context).textTheme.headline4,
            ),
          ],
        ),
      ),
      floatingActionButton: FloatingActionButton(
        onPressed: _incrementCounter,
        tooltip: 'Increment',
        child: Icon(Icons.add),
      ),
    );
  }
}

ImageSplashScreen

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
import 'dart:async';

import 'package:flutter/cupertino.dart';
import 'package:flutter/material.dart';

class ImageSplashScreen extends StatefulWidget {
  @override
  SplashScreenState createState() => SplashScreenState();
}

class SplashScreenState extends State<ImageSplashScreen> {
  startTime() async {
    var _duration = Duration(seconds: 2);
    return Timer(_duration, navigationPage);
  }

  void navigationPage() {
    Navigator.of(context).pushReplacementNamed("/home");
  }

  @override
  void initState() {
    super.initState();
    startTime();
  }

  @override
  Widget build(BuildContext context) {
    return Scaffold(
      body: Stack(
        fit: StackFit.expand,
        children: <Widget>[
          Image.asset(
            'assets/images/aeologic_logo.png',
            fit: BoxFit.fill,
            width: double.infinity,
            height: double.infinity,
          )
        ],
      ),
    );
  }
}

动态

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
import 'package:flutter/material.dart';
import 'package:test2/splash/AnimatedSplashScreen.dart';

void main() {
  runApp(MyApp());
}

class MyApp extends StatelessWidget {
  @override
  Widget build(BuildContext context) {
    return MaterialApp(
      title: 'Flutter Splash Demo',
      theme: ThemeData(
        primarySwatch: Colors.blue,
      ),
      home: AnimatedSplashScreen(),
      routes: <String, WidgetBuilder>{
        "/home": (BuildContext context) =>
            MyHomePage(title: 'Flutter Demo Home Page'),
      },
    );
  }
}

class MyHomePage extends StatefulWidget {
  MyHomePage({Key? key, required this.title}) : super(key: key);
  final String title;
  @override
  _MyHomePageState createState() => _MyHomePageState();
}

class _MyHomePageState extends State<MyHomePage> {
  int _counter = 0;

  void _incrementCounter() {
    setState(() {
      _counter++;
    });
  }

  @override
  Widget build(BuildContext context) {
    return Scaffold(
      appBar: AppBar(
        title: Text(widget.title),
      ),
      body: Center(
        child: Column(
          mainAxisAlignment: MainAxisAlignment.center,
          children: <Widget>[
            Text(
              'You have pushed the button this many times:',
            ),
            Text(
              '$_counter',
              style: Theme.of(context).textTheme.headline4,
            ),
          ],
        ),
      ),
      floatingActionButton: FloatingActionButton(
        onPressed: _incrementCounter,
        tooltip: 'Increment',
        child: Icon(Icons.add),
      ),
    );
  }
}

AnimatedSplashScreen

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
import 'dart:async';
import 'package:flutter/cupertino.dart';
import 'package:flutter/material.dart';

class AnimatedSplashScreen extends StatefulWidget {
  @override
  SplashScreenState createState() => SplashScreenState();
}

class SplashScreenState extends State<AnimatedSplashScreen>
    with SingleTickerProviderStateMixin {
  var _visible = true;

  late AnimationController animationController;
  late Animation<double> animation;

  startTime() async {
    var _duration = Duration(seconds: 3);
    return Timer(_duration, navigationPage);
  }

  void navigationPage() {
    Navigator.of(context).pushReplacementNamed("/home");
  }

  @override
  void initState() {
    super.initState();
    animationController = AnimationController(
        vsync: this, duration: Duration(seconds: 2));
    animation =
        CurvedAnimation(parent: animationController, curve: Curves.easeOut);

    animation.addListener(() => this.setState(() {}));
    animationController.forward();

    setState(() {
      _visible = !_visible;
    });
    startTime();
  }

  @override
  Widget build(BuildContext context) {
    return Scaffold(
      body: Stack(
        fit: StackFit.expand,
        children: <Widget>[
          Column(
            mainAxisAlignment: MainAxisAlignment.end,
            crossAxisAlignment: CrossAxisAlignment.center,
            mainAxisSize: MainAxisSize.min,
            children: <Widget>[
              Padding(
                  padding: EdgeInsets.only(bottom: 50.0),
                  child: Image.asset(
                    'assets/images/powered_by.png',
                    height: 30.0,
                    fit: BoxFit.scaleDown,
                  ))
            ],
          ),
          Column(
            mainAxisAlignment: MainAxisAlignment.center,
            children: <Widget>[
              Image.asset(
                'assets/images/logo.png',
                width: animation.value * 250,
                height: animation.value * 250,
              ),
            ],
          ),
        ],
      ),
    );
  }
}

视频

使用插件

1
2
dependencies:
  video_player: ^2.1.15
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
import 'package:flutter/material.dart';
import 'package:test2/splash/VideoSplashScreen.dart';

void main() {
  runApp(MyApp());
}

class MyApp extends StatelessWidget {
  @override
  Widget build(BuildContext context) {
    return MaterialApp(
      title: 'Flutter Splash Demo',
      theme: ThemeData(
        primarySwatch: Colors.blue,
      ),
      home: VideoSplashScreen(),
      routes: <String, WidgetBuilder>{
        "/home": (BuildContext context) =>
            MyHomePage(title: 'Flutter Demo Home Page'),
      },
    );
  }
}

class MyHomePage extends StatefulWidget {
  MyHomePage({Key? key, required this.title}) : super(key: key);
  final String title;
  @override
  _MyHomePageState createState() => _MyHomePageState();
}

class _MyHomePageState extends State<MyHomePage> {
  int _counter = 0;

  void _incrementCounter() {
    setState(() {
      _counter++;
    });
  }

  @override
  Widget build(BuildContext context) {
    return Scaffold(
      appBar: AppBar(
        title: Text(widget.title),
      ),
      body: Center(
        child: Column(
          mainAxisAlignment: MainAxisAlignment.center,
          children: <Widget>[
            Text(
              'You have pushed the button this many times:',
            ),
            Text(
              '$_counter',
              style: Theme.of(context).textTheme.headline4,
            ),
          ],
        ),
      ),
      floatingActionButton: FloatingActionButton(
        onPressed: _incrementCounter,
        tooltip: 'Increment',
        child: Icon(Icons.add),
      ),
    );
  }
}

VideoSplashScreen

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
import 'dart:async';
import 'package:flutter/cupertino.dart';
import 'package:flutter/material.dart';
import 'package:video_player/video_player.dart';

class VideoSplashScreen extends StatefulWidget {
  @override
  VideoState createState() => VideoState();
}

class VideoState extends State<VideoSplashScreen> {
  late VideoPlayerController playerController;
  late VoidCallback listener;

  @override
  void initState() {
    super.initState();
    listener = () {
      setState(() {});
    };
    initializeVideo();
    playerController.play();

    ///video splash display only 5 second you can change the duration according to your need
    startTime();
  }

  startTime() async {
    var _duration = Duration(seconds: 5);
    return Timer(_duration, navigationPage);
  }

  void navigationPage() {
    playerController.setVolume(0.0);
    playerController.removeListener(listener);
    //Navigator.of(context).pop(VIDEO_SPALSH);
    Navigator.of(context).pushReplacementNamed("/home");
  }

  void initializeVideo() {
    playerController =
        VideoPlayerController.asset('assets/videos/aeologic_logo.mp4')
          ..addListener(listener)
          ..setVolume(1.0)
          ..initialize()
          ..play();
  }

  @override
  void deactivate() {
    if (playerController != null) {
      playerController.setVolume(0.0);
      playerController.removeListener(listener);
    }
    super.deactivate();
  }

  @override
  void dispose() {
    if (playerController != null) playerController.dispose();
    super.dispose();
  }

  @override
  Widget build(BuildContext context) {
    return Scaffold(
        body: Stack(fit: StackFit.expand, children: <Widget>[
      AspectRatio(
          aspectRatio: 9 / 16,
          child: Container(
            child: (playerController != null
                ? VideoPlayer(
                    playerController,
                  )
                : Container()),
          )),
    ]));
  }
}

Flutter引导页

Flutter广告页
